The FET-MX952x-C SoM is developed and designed based on the NXP i.MX952 series processors, suitable for various edge applications, including automotive wireless connectivity, eCockpit systems, Industrial 4.0, and IoT platforms. This series supports NXP's SafeAssure functional safety (ASIL-B, SIL2) platform development, and features four Arm Cortex-A55 cores, an Arm Mali GPU, 4K VPU, ISP, ML acceleration NPU, and the Edgelock® secure enclave for security-related functions. The i.MX952 series uses the Energy Flex architecture, offering scalable real-time capabilities, security and application processing partitions, making it suitable for a wide range of platforms. The SoM enhances the exposure of the processor's functional pins, allowing for evaluation and secondary development. It has undergone thorough environmental, stability, and aging tests to guarantee reliable and stable operation.
Highlights:
- Advanced Graphics: GPU Mali-G310 supporting OpenGL ES 3.2, Vulkan 1.2, and OpenCL 3.0.
- Lightweight Edge AI: Built-in 2eTOPS NPU, suitable for lightweight edge computing applications.
- Rich Vision Interfaces: Integrated Image Signal Processor ( ISP), supporting 2x MIPI-CSI camera interfaces.
- Industrial Networking: Supports 3x CAN-FD, 3x Gigabit Ethernet ports, and TSN.
FET-MX952x-C SoM
Safety Features
i.MX 952 series has safety features that comply with the ISO 26262 ASIL-B and IEC 61508 SIL-2 functional safety standards
to support basic safety measures in automobiles and functional safety in
industrial control systems.
Multicore Heterogeneous Architecture
i.MX952x series features ARM Cortex-A55 high-performance cores along with a Cortex-M7 real-time core,
delivering both high computing performance and precise real-time control.
High-performance GPU
The advanced ARM Mali-G310 GPU supports OpenGL® ES 3.2, Vulkan® 1.2, and OpenCL 3.0, delivering stunning graphics and exceptional computing performance.
With the ability to manage two independent output streams, it offers versatile functions such as image rotation, resizing, color space conversion,blending, raster operations (ROP), scaling, distortion correction, and linear illumination.
High Computing Power to Empower Edge Applications
The i.MX952x chip integrates a built-in Neural Processing Unit (NPU) with a high computing power of up to 2 TOPS,
which enables excellent machine learning and deep learning capabilities, providing robust support for edge computing applications.
Rich CPU Interfaces
High Definition Decoding and Display Enhancement
The i.MX952x chip supports H.264 encoding & decoding and H.265 decoding with resolutions up to 4K, easily meeting the demands of playing high-definition videos.
At the same time, the chip also utilizes advanced display enhancement technology,which can further improve the contrast and color saturation of the picture, giving users a more stunning visual experience.
ISP Significantly Enhances Image Quality
The ISP technology integrated into the i.MX952xx chip supports various image sensors and is optimized for different application scenarios.
Whether it's for industrial inspection, robot vision or autonomous driving applications, the i.MX952x can provide clear and accurate image data.
Continuously Updated User Profiles
Broad Industry Applications
In multiple industries including industrial, medical, power, automotive transportation, environmental monitoring, smart cabins,
and IoT, the FET-MX952x-C SoM, with its high performance, multifunctionality, and industrial-grade advantages, coupled with Forlinx's competitive pricing
and comprehensive after-sales technical support, will help your products quickly enter the market and stay ahead in the industry.
▊ FET-MX952x-C SoM Parameters
| Specifications of the FET-MX952xx-C SoM | ||
|---|---|---|
| Processor | NXP i.MX952 | |
| CPU: 4 × Cortex-A55 @ 1.7 GHz | ||
| Cortex-M7: 800 MHz | ||
| Cortex-M33: 333 MHz | ||
| NPU: 2 eTOPS | ||
|
GPU: Mali-G310 OpenGL ES 3.2, Vulkan 1.2, OpenCL 3.0 |
||
|
VPU: Hardware decoding: H.264 and H.265, up to 4K @ 60 fps Hardware encoding: H.264 and H.265, up to 4K @ 30 fps |
||
| RAM | 2 GB / 4 GB / 8 GB LPDDR4X | |
| ROM | 64 GB eMMC | |
| Operating Voltage | 12 V DC | |
| Operating Temperature | Industrial grade: -40°C to +85°C | |
| Connector Type | Board-to-board (B2B) connectors (4 × 80-pin, 0.5 mm pitch, 2.0 mm mating height) | |
| Operating System | Linux 6.18 | |
| Flashing | TF card (MicroSD) / USB OTG | |
▊ SoM Function Parameters
| Functional Specifications of FET-MX952xx-C SoM | ||
|---|---|---|
| Function | QTY | Spec. |
| JTAG | 1 | 4-pin JTAG debugging interface |
| UART | ≤8 | Baud rate up to 5 Mbps |
| SPI | ≤8 | Supports both master and slave modes |
| XSPI | ≤1 | Supports 2 × Serial NOR flash and Serial NAND flash |
| CAN-FD | ≤3 | Supports ISO 11898-1 and CAN 2.0B |
| SAI | ≤5 | — |
| SD Card | ≤1 | Supports SD Card 3.0 |
| SDIO | ≤1 | Supports SDIO 3.0 |
| ADC | ≤8 | 1 × 12-bit, 8-channel ADC with a sampling rate of 1 MS/s |
| 1 Gbps Ethernet | ≤2 | Supports 1.8 V RMII/RGMII and TSN |
| 1 Gbps Ethernet | ≤1 | Supports SGMII; multiplexed with PCIe |
| USB 2.0 | 2 | Supports USB host or USB device mode |
| PCIe | 1 | Supports PCI Express Gen 3 |
| MIPI-DSI | ≤1 |
1 × 350 MHz, 4-lane MIPI-DSI interface, up to 2.5 Gbps Supports 4K @ 60 Hz or 3840 × 1440 @ 60 Hz |
| MIPI CSI-2 | ≤2 | 1 × 4-lane or 2 × 2-lane configuration |
| LVDS | 1 |
Supports resolutions up to 1080p @ 60 Hz 2 × 4-lane or 1 × 8-lane configuration |
| IIC | ≤7 | — |
| PDM | ≤1 | Supports an 8-channel microphone interface |
| SPDIF | ≤1 | — |
| PWM | ≤6 | — |
| GPIO | ≤n | — |
Note*: The parameters listed above are based on hardware design or theoretical CPU limits. Interfaces may be multiplexed; numbers represent maximum theoretical availability.
▊ Carrier Board
Build Faster with OK-MX952xx-C Development Board
Skip the complexity of hardware design with the OK-MX952xx-C development board. This production-ready platform combines a proven SoM + Carrier architecture, allowing you to bypass low-level circuitry and focus entirely on your application software. Seamlessly transition from initial concept to mass production with minimal risk, rich connectivity, and comprehensive multi-OS support.
Request a Quote
Fill out the form below for volume pricing or technical specifications. We'll get back to you within 24 hours.
▊ Ordering Information
1. Online Channels: We have an online store on Alibaba and DigiKey. Please contact us for details.
2. Direct Inquiry: For bulk orders, please email our sales team at [email protected].
3. Payment Method: Standard terms: 100% T/T (Telegraphic Transfer) in advance.
1. Dispatch Method: Orders are shipped via international express upon receipt of payment.
2. Lead Time: 5 working days for samples; 6 weeks for bulk orders.
3. Shipping Policy: Shipping and handling fees are the responsibility of the purchaser.
